Unity Tutorial

Video-Tutorial

Facemotion3d image Unity Tutorial Video on YouTubeyoutube.com

Wie Sie den Beispielavatar bewegen

1. download the script and sample avatar for Unity from the following page
Download Unity Script and sample avatar

2. Load the script and sample avatar into Unity.

3. Attach the script (UnityRecieve_Facemotion3d.cs) to a GameObject.

Unity Inspector setup

4. Press the Settings button in the Facemotion3d iOS app and find out the IP address of the iPhone.
Enter the iPhone's IP address in the "iOS_IP Address" field of the Unity script.

5. Turn on the "Game Start With Connect" checkbox in the Unity script.
Press the "Game Start" button, and the sample avatar will start moving.

Wie Sie Ihren eigenen Avatar bewegen

1. Load your original avatar into Unity.
Create a BlendShape with the same naming convention as the sample avatar.

2. Switch to the iOS app Settings → Streaming Settings → Unity tab.
Enter the avatar's bone name and other information here.

3. If you want to ignore the settings on the iOS side and specify the bone name on the Unity side, you can do so in the script on the Unity side.
Check the "Specify Object Name Inside Unity" checkbox.
Enter the name of the GameObject you want to move into the attached script.

4. Start the game and move the avatar.

So importieren Sie aufgezeichnete Daten in Unity

Facemotion3d image Unity Recorded Data Tutorial Video on YouTubeyoutube.com

1. record with the iOS application.

2. Press the Save button, save the recording data in .txt format, and send the data to your PC via email, etc.

3. Download the script to import the recording data into Unity from the following site.
https://drive.google.com/drive/folders/13CZliUbqZ9VihXAyyXaOJ7ji4twqBZY-?usp=sharing

4. Load the script into Unity.

5. Enter the name of the GameObject to which the animation will be applied.

6. Load the .txt file output from the iOS app.

Wie Sie VRM-Avatare bewegen

Download the script from the following URL and attach it to the GameObject.
https://drive.google.com/drive/folders/13CZliUbqZ9VihXAyyXaOJ7ji4twqBZY-?usp=sharing

Unity Inspector for VRM

In the inspector script, select the root object of the VRM and the GameObjects of the bones such as head, eyes and neck.
Turn on "Use ARKit BlendShape" to find and move the 52 blendshape BlendShapeClips.
